promethues监控k8s

适合二进制安装的k8s,其他基于kubeadmin部署的不需要创建etcd secret还要把Prometheus部署清单中关于etcd的删掉

创建命名空间

apiVersion: v1
kind: Namespace
metadata:
  name: monitor
  labels:
    name: monitor

创建etcd secret

kubectl create secret generic etcd-certs --from-file=ca.pem=/etc/kubernetes/ssl/ca.pem --from-file=etcd.pem=/etc/kubernetes/ssl/etcd.pem --from-file=etcd-key.pem=/etc/kubernetes/ssl/etcd-key.pem -n monitor

部署kube-state-metrics

apiVersion: apps/v1
kind: Deployment
metadata:
  name: kube-state-metrics
  namespace: monitor
  labels:
    k8s-app: kube-state-metrics
spec:
  selector:
    matchLabels:
      k8s-app: kube-state-metrics
      version: v1.8.0
  replicas: 1
  template:
    metadata:
      labels:
        k8s-app: kube-state-metrics
        version: v1.8.0
    spec:
      serviceAccountName: kube-state-metrics
      containers:
      - name: kube-state-metrics
        image: bitnami/kube-state-metrics:2.4.2
        imagePullPolicy: IfNotPresent
        ports:
        - name: http-metrics
          containerPort: 8080
        - name: telemetry
          containerPort: 8081
        readinessProbe:
          httpGet:
            path: /healthz
            port: 8080
          initialDelaySeconds: 5
          timeoutSeconds: 5
      - name: addon-resizer
        image: ibmcom/addon-resizer:2.1
        imagePullPolicy: IfNotPresent
        resources:
          limits:
            cpu: 100m
            memory: 200Mi
          requests:
            cpu: 100m
            memory: 200Mi
        env:
          - name: MY_POD_NAME
            valueFrom:
              fieldRef:
                fieldPath: metadata.name
          - name: MY_POD_NAMESPACE
            valueFrom:
              fieldRef:
                fieldPath: metadata.namespace
        volumeMounts:
          - name: config-volume
            mountPath: /etc/config
        command:
          - /pod_nanny
        #  - --config-dir=/etc/config
          - --container=kube-state-metrics
          - --cpu=100m
          - --extra-cpu=1m
          - --memory=100Mi
          - --extra-memory=2Mi
          - --threshold=5
          - --deployment=kube-state-metrics
      volumes:
        - name: config-volume
          configMap:
            name: kube-state-metrics-config
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: kube-state-metrics-config
  namespace: monitor
data:
  NannyConfiguration: |-
    apiVersion: nannyconfig/v1alpha1
    kind: NannyConfiguration
---
apiVersion: v1
kind: Service
metadata:
  name: kube-state-metrics
  namespace: monitor
  annotations:
    prometheus.io/scrape: 'true'
spec:
  ports:
  - name: http-metrics
    port: 8080
    targetPort: http-metrics
    protocol: TCP
  - name: telemetry
    port: 8081
    targetPort: telemetry
    protocol: TCP
  selector:
    k8s-app: kube-state-metrics
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: kube-state-metrics
  namespace: monitor
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: kube-state-metrics
rules:
- apiGroups: [""]
  resources:
  - configmaps
  - secrets
  - nodes
  - pods
  - services
  - resourcequotas
  - replicationcontrollers
  - limitranges
  - persistentvolumeclaims
  - persistentvolumes
  - namespaces
  - endpoints
  verbs: ["list", "watch"]
- apiGroups: ["apps"]
  resources:
  - statefulsets
  - daemonsets
  - deployments
  - replicasets
  verbs: ["list", "watch"]
- apiGroups: ["batch"]
  resources:
  - cronjobs
  - jobs
  verbs: ["list", "watch"]
- apiGroups: ["autoscaling"]
  resources:
  - horizontalpodautoscalers
  verbs: ["list", "watch"]
- apiGroups: ["networking.k8s.io", "extensions"]
  resources:
  - ingresses
  verbs: ["list", "watch"]
- apiGroups: ["storage.k8s.io"]
  resources:
  - storageclasses
  verbs: ["list", "watch"]
- apiGroups: ["certificates.k8s.io"]
  resources:
  - certificatesigningrequests
  verbs: ["list", "watch"]
- apiGroups: ["policy"]
  resources:
  - poddisruptionbudgets
  verbs: ["list", "watch"]

---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: kube-state-metrics-resizer
  namespace: monitor
rules:
- apiGroups: [""]
  resources:
  - pods
  verbs: ["get"]
- apiGroups: ["extensions","apps"]
  resources:
  - deployments
  resourceNames: ["kube-state-metrics"]
  verbs: ["get", "update"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: kube-state-metrics
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: kube-state-metrics
subjects:
- kind: ServiceAccount
  name: kube-state-metrics
  namespace: monitor
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: kube-state-metrics
  namespace: monitor
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: kube-state-metrics-resizer
subjects:
- kind: ServiceAccount
  name: kube-state-metrics
  namespace: monitor

创建Prometheus认证

apiVersion: v1
kind: ConfigMap
metadata:
  name: prometheus-auth
  namespace: monitor
data:
  webconfig.yml: |
    basic_auth_users:
      UnJRAXyk: $2y$10$Xdj.b5xW70/rdRm0BSPmAuaeuwAsoA16hZoEyKNZLmblNanm7JtvO

创建Prometheus cm

apiVersion: v1
kind: ConfigMap
metadata:
  name: prometheus-config
  namespace: monitor
data:
  prometheus.yml: |
    rule_files:
    - /etc/config/rules/*.rules
    global:
       scrape_interval: 30s      # 默认每30秒抓取一次
       scrape_timeout:  25s      # 默认每次抓取超时时间为25秒
       evaluation_interval: 30s  # 每30秒评估一次规则
    scrape_configs:
    - job_name: prometheus
      basic_auth:
        username: UnJRAXyk
        password: iQU~tBU9,Z
      static_configs:
      - targets:
        - localhost:9090
    - job_name: kubernetes-apiservers
      kubernetes_sd_configs:
      - role: endpoints
      relabel_configs:
      - action: keep
        regex: default;kubernetes;https
        source_labels:
        - __meta_kubernetes_namespace
        - __meta_kubernetes_service_name
        - __meta_kubernetes_endpoint_port_name
      scheme: https
      tls_config:
        ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
        insecure_skip_verify: true
      bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token

    - job_name: kubernetes-nodes-kubelet
      kubernetes_sd_configs:
      - role: node  # 发现集群中的节点
      relabel_configs:
      # 将标签(.*)作为新标签名，原有值不变
      - action: labelmap
        regex: __meta_kubernetes_node_label_(.+)
      scheme: https
      tls_config:
        ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
        insecure_skip_verify: true
      bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token

    - job_name: kubernetes-nodes-cadvisor
      kubernetes_sd_configs:
      - role: node
      relabel_configs:
      # 将标签(.*)作为新标签名，原有值不变
      - action: labelmap
        regex: __meta_kubernetes_node_label_(.+)
      - target_label: __metrics_path__
        replacement: /metrics/cadvisor
      scheme: https
      tls_config:
        ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
        insecure_skip_verify: true
      bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token

      metric_relabel_configs:
      - source_labels: [instance]
        separator: ;
        regex: (.+)
        target_label: node
        replacement: $1
        action: replace

    - job_name: kubernetes-service-endpoints
      kubernetes_sd_configs:
      - role: endpoints  # 从Service列表中的Endpoint发现Pod为目标
      basic_auth:
        username: UnJRAXyk
        password: iQU~tBU9,Z
      relabel_configs:
      # Service没配置注解prometheus.io/scrape的不采集
      - action: keep
        regex: true
        source_labels:
        - __meta_kubernetes_service_annotation_prometheus_io_scrape
      # 重命名采集目标协议
      - action: replace
        regex: (https?)
        source_labels:
        - __meta_kubernetes_service_annotation_prometheus_io_scheme
        target_label: __scheme__
      # 重命名采集目标指标URL路径
      - action: replace
        regex: (.+)
        source_labels:
        - __meta_kubernetes_service_annotation_prometheus_io_path
        target_label: __metrics_path__
      # 重命名采集目标地址
      - action: replace
        regex: ([^:]+)(?::\d+)?;(\d+)
        replacement: $1:$2
        source_labels:
        - __address__
        - __meta_kubernetes_service_annotation_prometheus_io_port
        target_label: __address__
      # 将K8s标签(.*)作为新标签名，原有值不变
      - action: labelmap
        regex: __meta_kubernetes_service_label_(.+)
      # 生成命名空间标签
      - action: replace
        source_labels:
        - __meta_kubernetes_namespace
        target_label: kubernetes_namespace
      # 生成Service名称标签
      - action: replace
        source_labels:
        - __meta_kubernetes_service_name
        target_label: kubernetes_name
    - job_name: etcd
      scheme: https
      tls_config:
        ca_file: /etc/prometheus/secrets/etcd-certs/ca.pem
        cert_file: /etc/prometheus/secrets/etcd-certs/etcd.pem
        key_file: /etc/prometheus/secrets/etcd-certs/etcd-key.pem
        insecure_skip_verify: false
      static_configs:
        - targets:
          - 172.18.60.219:2379
    - job_name: blackbox-http-2xx
      metrics_path: /probe
      params:
        module: [http_2xx]
      static_configs:
        - targets:
            - 'https://googgle.vip'
            - 'https://i09.net'
            - 'https://i09.vip'
            - 'https://userapi.jackpotparty.cc/api/public/maintain'
            - 'https://jackpp.cc'
            - 'https://jackpp.vip'
            - 'https://admin-phl.labubugame.cc'
            - 'https://data-phl.labubugame.cc'
      relabel_configs:
        - source_labels: [__address__]
          target_label: __param_target
        - source_labels: [__param_target]
          target_label: instance
        - target_label: __address__
          replacement: 'blackbox-exporter:9115'
    - job_name: kubernetes-pods
      kubernetes_sd_configs:
      - role: pod   # 发现所有Pod为目标
      relabel_configs:
      - action: keep
        regex: true
        source_labels:
        - __meta_kubernetes_pod_annotation_prometheus_io_scrape
      # 重命名采集目标指标URL路径
      - action: replace
        regex: (.+)
        source_labels:
        - __meta_kubernetes_pod_annotation_prometheus_io_path
        target_label: __metrics_path__
      # 重命名采集目标地址
      - action: replace
        regex: ([^:]+)(?::\d+)?;(\d+)
        replacement: $1:$2
        source_labels:
        - __address__
        - __meta_kubernetes_pod_annotation_prometheus_io_port
        target_label: __address__
      # 将K8s标签(.*)作为新标签名，原有值不变
      - action: labelmap
        regex: __meta_kubernetes_pod_label_(.+)
      # 生成命名空间标签
      - action: replace
        source_labels:
        - __meta_kubernetes_namespace
        target_label: kubernetes_namespace
      # 生成Service名称标签
      - action: replace
        source_labels:
        - __meta_kubernetes_pod_name
        target_label: kubernetes_pod_name
    alerting:
      alertmanagers:
      - static_configs:
          - targets: ["alertmanager:80"]

创建Prometheus rule

apiVersion: v1
kind: ConfigMap
metadata:
  name: prometheus-rules
  namespace: monitor
data:
  general.rules: |
    groups:
    - name: general.rules
      rules:
      - alert: k8s资源状态
        expr: up == 0
        for: 5m
        labels:
          severity: error
        annotations:
          summary: "k8s资源{{ $labels.job }}/{{ $labels.instance }}已停止工作"
  node.rules: |
    groups:
    - name: node.rules
      rules:
      - alert: k8s节点分区
        expr: |
          100 - (node_filesystem_free_bytes / node_filesystem_size_bytes) * 100 > 75
        for: 1m
        labels:
          severity: critical
        annotations:
          summary: "节点{{ $labels.instance }}分区{{ $labels.device }}使用率大于75%,当前值{{ $value }}%"
      - alert: k8s节点内存
        expr: |
          100 - (node_memory_MemFree_bytes+node_memory_Cached_bytes+node_memory_Buffers_bytes) / node_memory_MemTotal_bytes * 100 > 90
        for: 1m
        labels:
          severity: critical
        annotations:
          summary: "节点{{ $labels.instance }}内存使用率大于90%,当前值{{ $value }}%"
      - alert: k8s节点CPU
        expr: |
          100 - (avg(irate(node_cpu_seconds_total{mode="idle"}[5m])) by (instance) * 100) > 90
        for: 1m
        labels:
          severity: critical
        annotations:
          summary: "节点{{ $labels.instance }}CPU使用率大于90%,当前值{{ $value }}%"
      - alert: k8s节点状态
        expr: |
          kube_node_status_condition{condition="Ready",status="true"} == 0
        for: 1m
        labels:
          severity: error
        annotations:
          summary: '节点{{ $labels.node }}已经超过1分钟没有就绪,当前值{{ $value }}'
      - alert: k8s节点线程数
        expr: |
          sum(node_processes_threads) by(instance) >240000
        for: 1m
        labels:
          severity: critical
        annotations:
          summary: "节点{{ $labels.instance }}线程数已经接近最大,当前值{{ $value }}"
  pod.rules: |
    groups:
    - name: pod.rules
      rules:
      - alert: PodCPU
        expr: |
           sum(rate(container_cpu_usage_seconds_total{container!="", pod!=""}[5m])) by (pod, namespace) / sum(kube_pod_container_resource_limits{resource="cpu", container!=""}) by (pod, namespace) * 100 > 80
        for: 3m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }} Pod名称:{{ $labels.pod }}CPU使用大于80%,当前值{{ $value }}%"
      - alert: Pod内存
        expr: |
           sum(container_memory_working_set_bytes{pod!=""}) by(pod, namespace) / sum(container_spec_memory_limit_bytes{pod!=""}) by(pod, namespace)  * 100 != +inf > 80
        for: 3m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }} Pod名称:{{ $labels.pod }}内存使用大于80%,当前值{{ $value }}%"
      - alert: Pod网路入口流量
        expr: |
           sum(rate(container_network_receive_bytes_total{image!="",name=~"^k8s_.*"}[5m])) by (pod,namespace,node) > 8000000000
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "节点:{{ $labels.node }}|命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}入口流量大于800MB/s,当前值{{ $value }}K/s"
      - alert: Pod网路出口流量
        expr: |
           sum(rate(container_network_transmit_bytes_total{image!="",name=~"^k8s_.*"}[5m])) by (pod,namespace,node) > 8000000000
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "节点:{{ $labels.node }}|命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}出口流量大于800MB/s,当前值{{ $value }}K/s"
      - alert: Pod网路错误
        expr: |
           sum by (pod, namespace) (rate(container_network_receive_errors_total[5m]) + rate(container_network_transmit_errors_total[5m])) > 10
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}5分钟内网络错误多次,当前值{{ $value }}"
      - alert: Pod重启
        expr: |
           increase(kube_pod_container_status_restarts_total[1m]) > 0
        for: 0m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}5分钟内重启多次,当前值{{ $value }}"
      - alert: Pod状态Failed
        expr: |
           sum(kube_pod_status_phase{phase="Failed"}) by (pod,namespace) > 0
        for: 0m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}状态Failed"
      - alert: Pod状态Pending
        expr: |
           sum(kube_pod_status_phase{phase="Pending"}) by (pod,namespace) > 0
        for: 1m
        labels:
          severity: warning
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}状态Pending"
      - alert: Pod拉取镜像
        expr: |
           sum by(namespace,pod) (kube_pod_container_status_waiting_reason{reason="ErrImagePull"}) == 1
        for: 1m
        labels:
          severity: warning
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}拉取镜像失败ErrImagePull"
      - alert: Pod拉取镜像
        expr: |
           sum by(namespace,pod) (kube_pod_container_status_waiting_reason{reason="ImagePullBackOff"}) == 1
        for: 1m
        labels:
          severity: warning
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}拉取镜像失败ImagePullBackOff"
      - alert: Pod运行状态CrashLoopBackOff
        expr: |
           sum by(namespace,pod) (kube_pod_container_status_waiting_reason{reason="CrashLoopBackOff"}) == 1
        for: 0m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}状态为CrashLoopBackOff"
      - alert: Pod运行状态InvalidImageName
        expr: |
           sum by(namespace,pod) (kube_pod_container_status_waiting_reason{reason="InvalidImageName"}) == 1
        for: 0m
        labels:
          severity: critical
        annotations:
          summary: "命名空间: {{ $labels.namespace }} | Pod名称: {{ $labels.pod }}状态为InvalidImageName"
      - alert: Pod运行状态CreateContainerConfigError
        expr: |
           sum by(namespace,pod) (kube_pod_container_status_waiting_reason{reason="CreateContainerConfigError"}) == 1
        for: 0m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}状态为CreateContainerConfigError"
      - alert: default空间下Pod线程数超过阈值
        expr: |
          sum by (pod, namespace) (container_threads{container!="POD",container!="",namespace="default",pod!~"redis.*"}) > 3000
        for: 10m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}线程数大于3000,当前值{{ $value }}"
      - alert: Pod线程数超过阈值
        expr: |
          sum by (pod, namespace) (container_threads{container!="POD",container!="",pod=~"redis.*|haproxy.*"}) > 10000
        for: 10m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}线程数大于10000,当前值{{ $value }}"
      - alert: kube-apiservers线程数超过阈值
        expr: |
          go_threads{ job="kubernetes-apiservers"} > 1500
        for: 10m
        labels:
          severity: critical
        annotations:
          summary: "节点:{{ $labels.instance }}kube-apiservers线程数过高大于1500,当前值{{ $value }}"
      - alert: 节点容器线程数接近系统限制
        expr: |
          sum(container_threads{pod!=""}) by(instance) >202363
        for: 30m
        labels:
          severity: critical
        annotations:
          summary: "k8s节点:{{ $labels.instance }}线程数过接近系统限制,当前值{{ $value }}"
      - alert: PodOOMKilled
        expr: |
          kube_pod_container_status_last_terminated_reason{reason="OOMKilled"} == 1 and kube_pod_container_status_terminated == 1
        for: 0m
        labels:
          severity: critical
        annotations:
          summary: "命名空间:{{ $labels.namespace }}|Pod名称:{{ $labels.pod }}已经OOMKilled"
  volume.rules: |
    groups:
    - name: volume.rules
      rules:
      - alert: pvc状态为Lost
        expr: |
           sum by(namespace, persistentvolumeclaim) (kube_persistentvolumeclaim_status_phase{phase="Lost"}) == 1
        for: 1m
        labels:
          severity: critical
        annotations:
          summary: "{{ $labels.namespace }}/{{ $labels.persistentvolumeclaim }}状态为lost"
      - alert: pvc状态为Pending
        expr: |
           sum by(namespace, persistentvolumeclaim) (kube_persistentvolumeclaim_status_phase{phase="Pending"}) == 1
        for: 1m
        labels:
          severity: critical
        annotations:
          summary: "{{ $labels.namespace }}/{{ $labels.persistentvolumeclaim }}状态为pending"
      - alert: pvc状态为Failed
        expr: |
           sum(kube_persistentvolume_status_phase{phase="Failed",job="kubernetes-service-endpoints"}) by (persistentvolume) == 1
        for: 2m
        labels:
          severity: critical
        annotations:
          summary: "{{ $labels.namespace }}/{{ $labels.persistentvolumeclaim }}状态为Failed"
  blackbox.rules: |
   groups:
   - name: blackbox
     rules:
     - alert: https网站状态
       expr: probe_success{job="blackbox-https"} == 0
       for: 1m
       labels:
         severity: critical
       annotations:
         summary: "https网站{{ $labels.instance }}不能访问"
     - alert: 网站访问时间
       expr: avg_over_time(probe_http_duration_seconds[1m]) > 10
       for: 1m
       labels:
         severity: critical
       annotations:
         summary: "网站{{ $labels.instance }}访问超过10s,当前值{{ $value }}"
  domain.rules: |
    groups:
    - name: domain-expiry-alerts
      rules:
      - alert: 域名过期时间
        expr: domain_expiry_days < 30
        for: 10m
        labels:
          severity: warning
        annotations:
          summary: "域名 {{ $labels.domain }} 将在 {{ $value }} 天后过期！"
  ssl.rules: |
   groups:
     - name: SSL证书即将过期
       rules:
       - alert: SSLCertificateExpiry
         expr: probe_ssl_earliest_cert_expiry - time() < 86400 * 10
         for: 5m
         labels:
           severity: warning
         annotations:
           summary: "域名{{ $labels.instance }}SSL证书将在10天内过期,当前值{{ $value }}天"
  redis.rules: |
    groups:
    - name: redis
      rules:
      - alert: redis内存
        expr: 100 * (redis_memory_used_bytes{instance=~"$instance"} / redis_memory_max_bytes{instance=~"$instance"}) > 80
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "{{ $labels.instance }}Redis使用内存大于80%,当前值{{ $value }}%"
      - alert: Redis连接数
        expr: redis_connected_clients{instance=~"$instance"} > 50000
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "{{ $labels.instance }}Redis连接数大于50000,当前值{{ $value }}"
      - alert: Redis内存碎片率
        expr: redis_mem_fragmentation_ratio{instance=~"$instance"} > 2
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "{{ $labels.instance }}Redis内存碎片率大于2,当前值{{ $value }}"
      - alert: Redis持久化
        expr: redis_rdb_last_bgsave_status{instance=~"$instance"} == 0 or redis_aof_last_write_status{instance=~"$instance"} == 0
        for: 1m
        labels:
          severity: critical
        annotations:
          summary: "{{ $labels.instance }}Redis持久化(RDB 或 AOF)失败"
      - alert: Redis主从延迟
        expr: redis_master_repl_offset{instance=~"$instance"} - redis_slave_repl_offset{instance=~"$instance"} > 10485760  # 10MB
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "{{ $labels.instance }}redis主从延迟过高"

创建Prometheus pvc

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: prometheus-pv-claim
  namespace: monitor
  labels:
    app: prometheus
spec:
  storageClassName: nfs
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 100Gi

部署Prometheus

apiVersion: apps/v1
kind: Deployment
metadata:
  name: prometheus
  namespace: monitor
  labels:
    k8s-app: prometheus
spec:
  replicas: 1
  selector:
    matchLabels:                  ##下面匹配的是这里的标签
      k8s-app: prometheus
  template:
    metadata:
      labels:
        k8s-app: prometheus
    spec:
 #     affinity:
 #       podAntiAffinity:    ##pod反亲和
 #         requiredDuringSchedulingIgnoredDuringExecution:   ##强制匹配，不满足就不调度
 #           - topologyKey: 'kubernetes.io/hostname'         ##设置拓扑域为主机
 #             labelSelector:                                ## 匹配标签 k8s-app 等于 prometheus
 #               matchExpressions:
 #                 - key: k8s-app
 #                   operator: In
 #                   values:
 #                     - prometheus
 #       nodeAffinity:     ##节点亲和，简单实用更建议自定义标签后使用nodeSelector字段
 #         requiredDuringSchedulingIgnoredDuringExecution: ##强制匹配，不满足就不调度
 #           nodeSelectorTerms:
 #             - matchExpressions:                 ## 匹配主机名称 等于是 xxx1 或 xxx2
 #                 - key: kubernetes.io/hostname
 #                   operator: In
 #                   values:
 #                     - xxx1
 #                     - xxx2
      serviceAccountName: prometheus
      initContainers:
      - name: "init-chown-data"
        image: busybox:latest
        imagePullPolicy: "IfNotPresent"
        command: ["chown", "-R", "65534:65534", "/data"]
        volumeMounts:
        - name: prometheus-data
          mountPath: /data
          subPath: ""
      containers:
        - name: prometheus-server-configmap-reload
          image: jimmidyson/configmap-reload:v0.7.1
          imagePullPolicy: "IfNotPresent"
          args:
            - --volume-dir=/etc/config
            - --webhook-url=http://localhost:9090/-/reload
          volumeMounts:
            - name: config-volume
              mountPath: /etc/config
              readOnly: true
            - mountPath: /etc/localtime
              name: timezone
        - name: prometheus-server
          image: prom/prometheus:v2.45.1
          imagePullPolicy: "IfNotPresent"
          args:
            - --config.file=/etc/config/prometheus.yml
            - --storage.tsdb.path=/data
            - --storage.tsdb.retention.time=30d #60天
            - --web.console.libraries=/etc/prometheus/console_libraries
            - --web.console.templates=/etc/prometheus/consoles
            - --web.enable-lifecycle
            - --web.config.file=/etc/prometheus/basicauth/webconfig.yml
          ports:
            - containerPort: 9090
          readinessProbe:
            httpGet:
              httpHeaders:
              - name: Authorization
                value: Basic VW5KUkFYeWs6aVFVfnRCVTksWg==
              path: /-/ready
              port: 9090
            initialDelaySeconds: 30
            timeoutSeconds: 30
          livenessProbe:
            httpGet:
              httpHeaders:
              - name: Authorization
                value: Basic VW5KUkFYeWs6aVFVfnRCVTksWg==
              path: /-/healthy
              port: 9090
            initialDelaySeconds: 30
            timeoutSeconds: 30
          volumeMounts:
            - name: config-volume
              mountPath: /etc/config
            - name: prometheus-data
              mountPath: /data
              subPath: ""
            - name: prometheus-rules
              mountPath: /etc/config/rules
            - mountPath: /etc/localtime
              name: timezone
            - mountPath: /etc/prometheus/basicauth
              name: basic-auth
            - name: etcd-certs
              mountPath: /etc/prometheus/secrets/etcd-certs
      volumes:
        - name: config-volume
          configMap:
            name: prometheus-config
        - name: prometheus-rules
          configMap:
            name: prometheus-rules
        - name: prometheus-data
          persistentVolumeClaim:
            claimName: prometheus-pv-claim
        - name: timezone
          hostPath:
            path: /usr/share/zoneinfo/Asia/Shanghai
        - name: basic-auth
          configMap:
            name: prometheus-auth
        - name: etcd-certs
          secret:
            secretName: etcd-certs

---
apiVersion: v1
kind: Service
metadata:
  name: prometheus
  namespace: monitor
spec:
  type: NodePort
  ports:
    - name: http
      port: 9090
      protocol: TCP
      targetPort: 9090
      nodePort: 30089
  selector:
    k8s-app: prometheus
---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: prometheus
  namespace: monitor
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: prometheus
rules:
  - apiGroups:
      - ""
    resources:
      - nodes
      - nodes/metrics
      - services
      - endpoints
      - pods
    verbs:
      - get
      - list
      - watch
  - apiGroups:
      - ""
    resources:
      - configmaps
    verbs:
      - get
  - nonResourceURLs:
      - "/metrics"
    verbs:
      - get
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: prometheus
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: prometheus
subjects:
- kind: ServiceAccount
  name: prometheus
  namespace: monitor

创建node_erporter 认证

apiVersion: v1
kind: ConfigMap
metadata:
  name: node-exporter-auth
  namespace: monitor
data:
  config.yml: |
    basic_auth_users:
      UnJRAXyk: $2y$10$Xdj.b5xW70/rdRm0BSPmAuaeuwAsoA16hZoEyKNZLmblNanm7JtvO

部署node_erporter

apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: node-exporter
  namespace: monitor
  labels:
    k8s-app: node-exporter
spec:
  selector:
    matchLabels:
      version: v1.3.1
  template:
    metadata:
      labels:
        k8s-app: node-exporter
        version: v1.3.1
    spec:
      tolerations:
      - operator: "Exists"
      containers:
        - name: prometheus-node-exporter
          image: prom/node-exporter:v1.7.0
          imagePullPolicy: IfNotPresent
          ports:
          - name: metrics
            containerPort: 9100
            hostPort: 9100
          resources:
            limits:
              cpu: 250m
              memory: 180Mi
            requests:
              cpu: 102m
              memory: 180Mi
          volumeMounts:
          - mountPath: /host/proc
            name: proc
          - mountPath: /host/sys
            name: sys
          - mountPath: /host
            name: rootfs
          - mountPath: /etc/node/basicauth
            name: basic-auth
          args:
          - --collector.processes
          - --collector.systemd
          - --path.procfs=/host/proc
          - --path.sysfs=/host/sys
          - --path.rootfs=/host
          - --web.config.file=/etc/node/basicauth/config.yml
      hostNetwork: true
      hostPID: true
      securityContext:
        runAsNonRoot: true
        runAsUser: 65534
      volumes:
      - name: proc
        hostPath:
          path: /proc
      - name: sys
        hostPath:
          path: /sys
      - name: rootfs
        hostPath:
          path: /
      - name: basic-auth
        configMap:
          name: node-exporter-auth
---
apiVersion: v1
kind: Service
metadata:
  name: node-exporter
  namespace: monitor
  annotations:
    prometheus.io/scrape: "true"
spec:
  clusterIP: None
  ports:
    - name: metrics
      port: 9100
      protocol: TCP
      targetPort: 9100
  selector:
    k8s-app: node-exporter

创建altermanager cm

apiVersion: v1
kind: ConfigMap
metadata:
  name: alertmanager-config
  namespace: monitor
data:
  alertmanager.yml: |-
    global:
      resolve_timeout: 5m
    route:
      group_by: ['alertname', 'cluster']
      group_wait: 10s
      group_interval: 10s
      repeat_interval: 5m
      receiver: 'telegram'
    templates:
    - '/etc/alertmanager/template/telegram.tmpl'
    receivers:
    - name: 'telegram'
      telegram_configs:
      - bot_token: 7808485242:AAHSIl3F7XSzvnDC1h4jYZtzYD9JkahZVHg
        api_url: https://api.telegram.org
        chat_id: -4695150894
        parse_mode: HTML
        message: '{{ template "telegram.message". }}'
        send_resolved: true

创建altermanager 告警模板

#自定义告警模板
apiVersion: v1
kind: ConfigMap
metadata:
  name: alertmanager-template-volume
  namespace: monitor
data:
  telegram.tmpl: |
    {{ define "telegram.message" }}
    {{ if gt (len .Alerts.Firing) 0 }}
    🔥🔥🔥🔥🔥🔥触发告警 ({{ .Alerts.Firing | len }}条)
    {{ range .Alerts }}
    ---
    🔴 告警名称: {{ .Labels.alertname }}
    🔴 告警级别: {{ .Labels.severity }}
    🔴 告警内容: {{ .Annotations.summary }}
    🔴 触发时间: {{ (.StartsAt.Add 28800e9).Format "2006-01-02 15:04:05" }}
    {{ end }}
    {{ end }}

    {{ if gt (len .Alerts.Resolved) 0 }}
    ✅✅✅✅✅✅恢复告警 ({{ .Alerts.Resolved | len }}条)
    {{ range .Alerts }}
    ---
    🟢 告警名称: {{ .Labels.alertname }}
    🟢 告警级别: {{ .Labels.severity }}
    🟢 告警内容: {{ .Annotations.summary }}
    🟢 触发时间: {{ (.StartsAt.Add 28800e9).Format "2006-01-02 15:04:05" }}
    🟢 恢复时间: {{ (.EndsAt.Add 28800e9).Format "2006-01-02 15:04:05" }}
    {{ end }}
    {{ end }}
    {{ end }}

创建altermanager pvc

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: alertmanager-pv-claim
  namespace: monitor
  labels:
    app: alertmanager
spec:
  storageClassName: nfs
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 20Gi

部署altermanager

apiVersion: apps/v1
kind: Deployment
metadata:
  name: alertmanager
  namespace: monitor
spec:
  replicas: 1
  selector:
    matchLabels:
      k8s-app: alertmanager
      version: v0.26.0
  template:
    metadata:
      labels:
        k8s-app: alertmanager
        version: v0.26.0
    spec:
      containers:
        - name: prometheus-alertmanager
          image: prom/alertmanager:v0.26.0
          imagePullPolicy: "IfNotPresent"
          args:
            - --config.file=/etc/alertmanager/alertmanager.yml
            - --storage.path=/alertmanager
            - --cluster.advertise-address=0.0.0.0:9093
          ports:
            - containerPort: 9093
          readinessProbe:
            httpGet:
              path: /#/status
              port: 9093
            initialDelaySeconds: 30
            timeoutSeconds: 30
          volumeMounts:
            - name: config-volume
              mountPath: /etc/alertmanager
            - name: config-template-volume
              mountPath: /etc/alertmanager/template
            - name: storage-volume
              mountPath: "/alertmanager"
              subPath: ""
            - mountPath: /etc/localtime
              name: timezone
          resources:
            limits:
              cpu: 40m
              memory: 200Mi
            requests:
              cpu: 40m
              memory: 100Mi
      volumes:
        - name: config-volume
          configMap:
            name: alertmanager-config
        - name: config-template-volume
          configMap:
            name: alertmanager-template-volume
        - name: storage-volume
          persistentVolumeClaim:
            claimName: alertmanager-pv-claim
        - name: timezone
          hostPath:
            path: /usr/share/zoneinfo/Asia/Shanghai
---
apiVersion: v1
kind: Service
metadata:
  name: alertmanager
  namespace: monitor
  labels:
    kubernetes.io/cluster-service: "true"
    addonmanager.kubernetes.io/mode: Reconcile
    kubernetes.io/name: "Alertmanager"
spec:
  type: "ClusterIP"
  ports:
    - name: http
      port: 80
      protocol: TCP
      targetPort: 9093
  selector:
    k8s-app: alertmanager

创建blackbox cm

apiVersion: v1
kind: ConfigMap
metadata:
  name: blackbox
  namespace: monitor
data:
  blackbox.yml: |-
    modules:
      http_2xx:
        prober: http
        timeout: 10s
        http:
          valid_status_codes: [200,204,301,302,304]
          method: GET
          follow_redirects: true
          preferred_ip_protocol: "ip4"
      http_post_2xx:
        prober: http
        timeout: 10s
        http:
          preferred_ip_protocol: "ip4"
          method: POST
          valid_status_codes: [200,204,301,302,304]
      tcp_connect:
        prober: tcp
        timeout: 10s
      ping:
        prober: icmp
        timeout: 10s
        icmp:
          preferred_ip_protocol: "ip4"

部署blackbox-exporter

apiVersion: v1
kind: Service
metadata:
  name: blackbox-exporter
  namespace: monitor
  labels:
    app: blackbox-exporter
spec:
  type: ClusterIP
  ports:
  - name: http
    port: 9115
    targetPort: 9115
  selector:
    app: blackbox-exporter

---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: blackbox-exporter
  namespace: monitor
spec:
  replicas: 1
  selector:
    matchLabels:
      app: blackbox-exporter
  template:
    metadata:
      labels:
        app: blackbox-exporter
    spec:
      containers:
      - name: blackbox-exporter
        image: prom/blackbox-exporter:v0.25.0
        ports:
        - name: http
          containerPort: 9115
        args:
          - --config.file=/etc/blackbox_exporter/blackbox.yml
        readinessProbe:
          httpGet:
            path: /-/ready
            port: 9115
          initialDelaySeconds: 5
          timeoutSeconds: 5
        livenessProbe:
          httpGet:
            path: /-/healthy
            port: 9115
          initialDelaySeconds: 10
          timeoutSeconds: 5
        volumeMounts:
        - name: config-volume
          mountPath: /etc/blackbox_exporter
      volumes:
      - name: config-volume
        configMap:
          name: blackbox

以下是相关的部署yaml下载地址
