centos安装gluster集群
设置时间同步，每天执行，如果可以上网直接阿里云ntpserver，不能上网安装ntpd同步
yum install ntpdate -y
ntpdate ntp.aliyun.com
echo '*/3 * * * * /usr/bin/ntpdate ntp.aliyun.com' >> /var/spool/cron/root关闭selinux每台执行
setenforce 0
sed -i "s/SELINUX=enforcing/SELINUX=disabled/g" /etc/selinux/config关闭防火墙每台执行
systemctl stop firewalld && systemctl disable firewalld设置主机名和hosts文件,每台执行
hostnamectl set-hostname gluster01
hostnamectl set-hostname gluster02
hostnamectl set-hostname gluster03
cat >>/etc/hosts <<EOF
192.168.2.233 gluster01
192.168.2.234 gluster02
192.168.2.235 gluster03
EOFgluster 服务端+客户端 配(gluster fs官方源)每台执行(gluster9才执行)忽略
yum install fuse rpcbind -y
yum install ./*.rpm （rpm放在123盘，glusterfs目录里）
systemctl enable glusterd --now
systemctl status glusterdk8snode节点需要安装glusterfs-fuse
yum install glusterfs-fuse -y3台服务器建立连接，只需要找其中1台，连接另外2台即可,在gluster01上执行
gluster peer probe gluster02
gluster peer probe gluster03
验证
gluster peer status创建分布式卷
gluster volume create mydata replica 3 gluster01:/glusterdb gluster02:/glusterdb gluster03:/glusterdb force
gluster volume start mydata
gluster volume infoHeketi安装
两种部署方式
1、物理机部署
1.1、物理机部署(在一台服务器上执行)
配置Heketi YUM源
yum -y install centos-release-gluster
安装Heketi
1、k8s集群master节点安装
yum -y install heketi heketi-client1.2、heketi服务器节点修改Heketi配置文件
需要说明的是，heketi有三种executor，分别为mock、ssh、kubernetes，建议在测试环境使用mock，生产环境使用ssh，当glusterfs以容器的方式部署在kubernetes上时，才使用kubernetes。我们这里将glusterfs和heketi独立部署，使用ssh的方式
cp /etc/heketi/heketi.json{,.bak}
cat /etc/heketi/heketi.json
{
"_port_comment": "Heketi Server Port Number",
"port": "18080", 修改为18080，防止与其它端口冲突
"_use_auth": "Enable JWT authorization. Please enable for deployment",
"use_auth": true, 开启用户认证
"_jwt": "Private keys for access",
"jwt": {
"_admin": "Admin has access to all APIs",
"admin": {
"key": "adminkey" 用户认证的key
},
"_user": "User only has access to /volumes endpoint",
"user": {
"key": "My Secret"
}
},
"_glusterfs_comment": "GlusterFS Configuration",
"glusterfs": {
"_executor_comment": [
"Execute plugin. Possible choices: mock, ssh",
"mock: This setting is used for testing and development.",
" It will not send commands to any node.",
"ssh: This setting will notify Heketi to ssh to the nodes.",
" It will need the values in sshexec to be configured.",
"kubernetes: Communicate with GlusterFS containers over",
" Kubernetes exec api."
],
"executor": "ssh", 访问glusterfs集群的方法
"_sshexec_comment": "SSH username and private key file information",
"sshexec": {
"keyfile": "/etc/heketi/heketi_key",
访问glusterfs集群使用的私钥，需要提前在k8s集群master节点生成
并copy到glusterfs集群所有节点,需要从/root/.ssh/id_rsa复制到此处才可以使用。
"user": "root", 认证使用的用户
"port": "22", ssh连接使用的端口
"fstab": "/etc/fstab" 挂载的文件系统
},
"_kubeexec_comment": "Kubernetes configuration",
"kubeexec": {
"host" :"https://kubernetes.host:8443",
"cert" : "/path/to/crt.file",
"insecure": false,
"user": "kubernetes username",
"password": "password for kubernetes user",
"namespace": "OpenShift project or Kubernetes namespace",
"fstab": "Optional: Specify fstab file on node. Default is /etc/fstab"
},
"_db_comment": "Database file name",
"db": "/var/lib/heketi/heketi.db", 数据库位置
"_loglevel_comment": [
"Set log level. Choices are:",
" none, critical, error, warning, info, debug",
"Default is warning"
],
"loglevel" : "warning" 修改日志级别
}
}1.3、设置ssh免密登陆，一台上执行,这里k8smaster上执行
ssh-keygen
for i in 192.168.2.{233..235};do echo ">>> $i";ssh-copy-id $i;done
for i in gluster{01..03};do echo ">>> $i";ssh-copy-id $i;done
复制私密到/etc/heketi目录
cp .ssh/id_rsa /etc/heketi/heketi_key1.4、启动Heketi,这里k8smaster上执行
chown heketi:heketi /etc/heketi/ -R || chown heketi:heketi /var/lib/heketi -R
systemctl enable heketi
systemctl start heketi
systemctl status heketi1.5、为 Heketi 创建拓扑配置文件，该文件包含添加到 Heketi 的集群、节点和磁盘的信息
vi /etc/heketi/topology.json
示例文件：
{
"clusters": [
{
"nodes": [
{
"node": {
"hostnames": {
"manage": [
"192.168.0.2"
],
"storage": [
"192.168.0.2"
]
},
"zone": 1
},
"devices": [
"/dev/vdd"
]
},
{
"node": {
"hostnames": {
"manage": [
"192.168.0.3"
],
"storage": [
"192.168.0.3"
]
},
"zone": 1
},
"devices": [
"/dev/vdd"
]
},
{
"node": {
"hostnames": {
"manage": [
"192.168.0.4"
],
"storage": [
"192.168.0.4"
]
},
"zone": 1
},
"devices": [
"/dev/vdd"
]
}
]
}
]
}1.6、加载 topology.json 文件
export HEKETI_CLI_SERVER=http://192.168.2.230:18080
heketi-cli --user admin --secret 'adminkey' topology load --json=/etc/heketi/topology.json
查看集群信息
heketi-cli --user admin --secret 'adminkey' topology info1.7、查看集群信息
heketi-cli --user admin --secret 'adminkey' cluster info 2d9e11adede04fe6d07cb81c5a1a7ea41.8、k8s调用glusterfs
vi glusterfs-sc.yaml
apiVersion: v1
kind: Secret
metadata:
name: heketi-secret
namespace: kube-system
type: kubernetes.io/glusterfs
data:
key: "MTIzNDU2" #请替换为您自己的密钥。Base64 编码。
---
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
annotations:
storageclass.beta.kubernetes.io/is-default-class: "true"
storageclass.kubesphere.io/supported-access-modes: '["ReadWriteOnce","ReadOnlyMany","ReadWriteMany"]'
name: glusterfs
parameters:
clusterid: "21240a91145aee4d801661689383dcd1" #请替换为您自己的 GlusterFS 集群 ID。
gidMax: "50000"
gidMin: "40000"
restauthenabled: "true"
resturl: "http://192.168.0.2:8080" #Gluster REST 服务/Heketi 服务 URL 可按需供应 gluster 存储卷。请替换为您自己的 URL。
restuser: admin
secretName: heketi-secret
secretNamespace: kube-system
volumetype: "replicate:2" #请替换为您自己的存储卷类型。
provisioner: kubernetes.io/glusterfs
reclaimPolicy: Delete
volumeBindingMode: Immediate
allowVolumeExpansion: true2.1、在k8s中部署
2.1.1、Heketi配置文件
需要说明的是，heketi有三种executor，分别为mock、ssh、kubernetes，建议在测试环境使用mock，生产环境使用ssh，当glusterfs以容器的方式部署在kubernetes上时，才使用kubernetes。我们这里将glusterfs和heketi独立部署，使用ssh的方式。vim heketi.json
{
"_port_comment": "Heketi Server Port Number",
"port": "18080", 修改为18080，防止与其它端口冲突
"_use_auth": "Enable JWT authorization. Please enable for deployment",
"use_auth": true, 开启用户认证
"_jwt": "Private keys for access",
"jwt": {
"_admin": "Admin has access to all APIs",
"admin": {
"key": "adminkey" 用户认证的key
},
"_user": "User only has access to /volumes endpoint",
"user": {
"key": "userkey"
}
},
"_glusterfs_comment": "GlusterFS Configuration",
"glusterfs": {
"_executor_comment": [
"Execute plugin. Possible choices: mock, ssh",
"mock: This setting is used for testing and development.",
" It will not send commands to any node.",
"ssh: This setting will notify Heketi to ssh to the nodes.",
" It will need the values in sshexec to be configured.",
"kubernetes: Communicate with GlusterFS containers over",
" Kubernetes exec api."
],
"executor": "ssh",
"_sshexec_comment": "SSH username and private key file information",
"sshexec": {
"keyfile": "/usr/share/keys/heketi_key",
"user": "root",
"port": "22",
"fstab": "/etc/fstab"
},
"_kubeexec_comment": "Kubernetes configuration",
"kubeexec": {
"host" :"https://kubernetes.host:8443",
"cert" : "/path/to/crt.file",
"insecure": false,
"user": "kubernetes username",
"password": "password for kubernetes user",
"namespace": "OpenShift project or Kubernetes namespace",
"fstab": "/etc/fstab"
},
"_db_comment": "Database file name",
"db": "/var/lib/heketi/heketi.db",
"_loglevel_comment": [
"Set log level. Choices are:",
" none, critical, error, warning, info, debug",
"Default is warning"
],
"loglevel" : "debug"
}
}
kubectl create configmap heketi-config --from-file=/root/heketi.json2.1.2、设置ssh免密登陆，一台上执行,这里k8smaster上执行
ssh-keygen
for i in 192.168.2.{233..235};do echo ">>> $i";ssh-copy-id $i;done
for i in gluster{01..03};do echo ">>> $i";ssh-copy-id $i;done
cp .ssh/id_rsa .ssh/heketi_key
kubectl create secret generic ssh-key-secret --from-file=.ssh/heketi_key2.1.3、heketi deploy部署yaml，这里先设置hostpath方式挂在，待把gluster 磁盘初始化完成和创建heketi的pvc之后改成动态存储 vim heketi-deployment.yaml
---
kind: Service
apiVersion: v1
metadata:
name: heketi
namespace: heketi
labels:
glusterfs: heketi-service
heketi: service
spec:
selector:
app: heketi
ports:
- name: heketi
port: 18080
targetPort: 18080
---
kind: Deployment
apiVersion: apps/v1
metadata:
name: heketi-deployment
namespace: heketi
labels:
app: heketi
annotations:
description: Defines how to deploy Heketi
spec:
replicas: 1
selector:
matchLabels:
app: heketi
template:
metadata:
name: heketi
labels:
app: heketi
spec:
containers:
- name: heketi
image: heketi/heketi:dev
imagePullPolicy: IfNotPresent
volumeMounts:
- name: keys
mountPath: /usr/share/keys/heketi_key
subPath: heketi_key
- name: config
mountPath: /etc/heketi
- name: db
mountPath: /var/lib/heketi
volumes:
- name: keys
secret:
secretName: ssh-key-secret
defaultMode: 0600
- name: config
configMap:
name: heketi-config
- name: db
hostPath:
path: /root/heketi2.1.3、为 Heketi 创建拓扑配置文件，该文件包含添加到 Heketi 的集群、节点和磁盘的信息
vi topology.json
示例文件：
{
"clusters": [
{
"nodes": [
{
"node": {
"hostnames": {
"manage": [
"192.168.0.2"
],
"storage": [
"192.168.0.2"
]
},
"zone": 1
},
"devices": [
"/dev/vdd"
]
},
{
"node": {
"hostnames": {
"manage": [
"192.168.0.3"
],
"storage": [
"192.168.0.3"
]
},
"zone": 1
},
"devices": [
"/dev/vdd"
]
},
{
"node": {
"hostnames": {
"manage": [
"192.168.0.4"
],
"storage": [
"192.168.0.4"
]
},
"zone": 1
},
"devices": [
"/dev/vdd"
]
}
]
}
]
}2.1.4、加载 topology.json 文件
kubectl exec -it heketi-deployment-6fd99bdcf6-drcd8 -n heketi -- bash
export HEKETI_CLI_SERVER=http://192.168.2.230:18080
heketi-cli --user admin --secret 'adminkey' topology load --json=/etc/heketi/topology.json
查看集群信息
heketi-cli --user admin --secret 'adminkey' topology info2.1.5、查看集群信息
heketi-cli --user admin --secret 'adminkey' cluster info 2d9e11adede04fe6d07cb81c5a1a7ea42.1.6、k8s调用glusterfs
vi glusterfs-sc.yaml
apiVersion: v1
kind: Secret
metadata:
name: heketi-secret
namespace: kube-system
type: kubernetes.io/glusterfs
data:
key: "MTIzNDU2" #请替换为您自己的密钥。Base64 编码。
---
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
annotations:
storageclass.beta.kubernetes.io/is-default-class: "true"
storageclass.kubesphere.io/supported-access-modes: '["ReadWriteOnce","ReadOnlyMany","ReadWriteMany"]'
name: glusterfs
parameters:
clusterid: "21240a91145aee4d801661689383dcd1" #请替换为您自己的 GlusterFS 集群 ID。
gidMax: "50000"
gidMin: "40000"
restauthenabled: "true"
resturl: "http://192.168.0.2:8080" #Gluster REST 服务/Heketi 服务 URL 可按需供应 gluster 存储卷。请替换为您自己的 URL。
restuser: admin
secretName: heketi-secret
secretNamespace: kube-system
volumetype: "replicate:2" #请替换为您自己的存储卷类型。
provisioner: kubernetes.io/glusterfs
reclaimPolicy: Delete
volumeBindingMode: Immediate
allowVolumeExpansion: true2.1.7、创建heketi pvc
vim heketi-pvc.yaml
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
name: heketi-glusterfs-pvc
namespace: heketi
spec:
accessModes:
- ReadWriteOnce
resources:
requests:
storage: 40Gi
storageClassName: glusterfs2.1.8、修改heketi存储方式，并复制数据到pvc
kubectl delete -f heketi-deployment.yaml
- name: db
hostPath:
path: /root/heketi
修改为
- name: db
persistentVolumeClaim:
claimName: heketi-glusterfs-pvc
使用df -h 命令查看heketi pvc挂在在哪台服务器的brick里面，拷贝/root/heketi/heketi.db,到brick里面,重新创建heketi pod
kubectl create -f heketi-deployment.yaml通过heketi-cli删除卷
export HEKETI_CLI_SERVER=http://192.168.2.230:18080
heketi-cli volume list --user admin --secret 'adminkey'
heketi-cli volume delete 67b94a72c0fd55533d242b48080e03e6 --user admin --secret 'adminkey'- 感谢你赐予我前进的力量
-
